SoundunitsAudioamplifiersSpeakersFAQ’s
Discontinued products
TBS5925 Window driver is upgrading to V2.0.0.6, which solved to lock S2 signal loss packet problem. TBS5925 Linux Driver is updated to v160405., which has below updating:. improve 6909 signal quality. QAM B support for TBS 6704 (now it can lock both ATSC.
All prices shown below include 19% European VAT.
This means export prices for customers outside the European Union are off 19%!
1. Sound units
All offered digital sound units are reproducing original engine- and special sounds. The engine range covers starting, engine idle, reeving up the engine, acceleration, speed dependent engine sound, returning to idle state and engine shut down. Available special sounds are horns, flaps, weapons, radio messages, depending on the kind of sound unit.
Up to two speed signals can be scanned directely at the receiver to determine the moving state of the model. This makes it ideal for tracked vehicles.
It can be used in combination with burshless or common DC motors.
To ensure maximum output power at large scale vehicles, a external amplifier can be used. Different amplifiers covering a lorge power range are on stock.
Universal switching outputs can be used for starting sound depending actions, like flashing a LED, move a motor, ..
A fully dynamic and sound synchronous smoke generator for exhaust simulation is also available.
The following control modes are possible:
Tbs Dtv Sound Cards & Media Devices Driver Download Windows 10
A: Encoder
This rotary switch / push button combination must be connected at a spare proportional channel of your transmitter.
For mechanical installatioin already present extension places of your TX can be used usually. (Only two wholes are necessary)
The desired sound is selcted by one of the 12 rotary switch position and triggerd by the push button.
This allows a convenient, quick and direct sound selction.
In principal the encoder is a simple potentiometer with 12 fix positions.
Price: 65 Euro
B: Direct control by a spare proportional channel of your radio
A common proportional channel, equipped with a 3-position switch at your TX can be used to control the soundunit.
This switch should have a neutral position and momentary contacts to both sides. Permanent switching is also possible, in case the switch is centered manually.
Control mode “Indirect Soundselection”
The desired sound is selected by flicking the switch x-time up (according to the desired sound number).
The selected sound is triggered by flicking the switch down.
A already selected sound can be triggerd multiple times without a new selection (f.e. MG bursts).
This mode allows triggering all sounds and functions loaded at the unit.
Control mode “Direct Soundselection”
The desired sound is simply selected by flicking the switch up (sound1) or down (sound2)
Control mode “Autostart”
This mode does not need any control channel. Fist acceleration of the motor starts the engine. If it runs 20s idel, it is shut down automatically.
This control mode does NOT offer any special sounds(f.e. horn).
For installing the soundsystem in your model, common RC-modelling solder skills are necessary. The offered componets are parts of a soundsystem, created by the customer.
Please see the manuals for further descriptions.
We have an extraordinary sound collection of different vehicles which is constantly enlarged.
We specialized on modern and historical tracked vehicles and aircrafts!
A list of all currently available sounds can be found in the Download section.
Please see also the Demo section.
NEW Soundmodule TBS Mini V2
The TBS Mini V2 is the next stop to the very successful TBS Mini V1.
New features:
- 16x larger sound memory, enough for 28 Minuts of sound
- Powerful 3W digital amplifier on board
- 4OHm and 8Ohm speakers can be used
- Volume controller on board
- New connector for 3rd party amplifiers -> See manual !
- Dimmension is 3mm wider
- Receiver supply must be in the range of 4-6V
Manual TBS Mini V2
Aditional features:
- Fully customer programmabel, free of charge sofware at Downloads
- Large FREE OF CHARGE sound libraries of original recordings (f.e. Corsair, ME109, Spitfire, Cessna, dif. Trucks)
- Soundquality 22KHz
- 16Mbit Soundmemory, enough for 93s of soundrecordings
- Internal 1,2W amplifier at 8 Ohm speakers
- External high power amplifiers available
(f.e. 2x40W at 2Ohm and 12V OR 50W at 8 Ohm and 50V supply) - Up to 6 electronic switching outputs
- activated by sound (f.e. Muzzle flashing with MG sound) or independant operation
- permanent, momentary or flashing mode adjustable
- direction flashing - Externel smoke generator for exhaust simulation (see below). Not recommended for aircrafts !
- Twodigital inputs for triggering sounds by a external signal
(f.e. Screaming tires at touch down, triggered by a switch) - Twoservo signal outputs, f.e. for retractable landing gears
- All connections done by plugs, no solderwork necessary
- Receiver signals are used for speedinformation, this allows brushless or DC Motor usage
- All connections horizontally -> full isolation and protection by shrinked plastic tube possible
- Fully assembeled in SMD technology (no heavy, vibration sensitive components)
- All wires included
- Very little dimensions and weight
- USB or RS232 programing interface by external adaptor (optional)
- Can be fully configured by free of charge PC software:
- you can make your own soundcreation or using the original Benedini sounds
-Firmware update, your unit can be updated by your own with the latest software - Plays two sounds simultaneously (engine plus a special sound) from TBS Flash Ver. 1.0.1.0 on
Technical Datas:
Supplyrange: 4V – max. 6V (from receiver)
Internal amplifier: 3W at 4 Ohm and 6V supply
Switching outputs: Minus switching, max. 12V/0,5A each
Dimensions: only 55 x 28 x 10mm (3mm wider than the TBS Mini V1)
Weight: about 6g
Prices TBS Mini:
Fully programed with your desired setting: 119 Euro
Accessory:
Programming cables: (only necessary fi you want to program the sound unit on your own)
- USB Programing cable:
TBS Mini: 18 Euro
- Special servo Y-cable for connecting a second speed controller in tank models: 6,50 Euro
- Encoder (optional control device to be installed in the transmitter, see above) 65 Euro
- Smoke generator for LAND vehicles (NO aircrafts) -> see Smoke Section.
External amplifiers (details below):
Speakers (details below)
Soundmodule TBS Mini V1(available as long as stock lasts)
Ideal for all kind of rc models.
Differences in comparison to the TBS Mini V2:
- smaller sound memory
- 1W analog amplifier
- no volume control on board
- all other functios are the same
Manual TBS Mini V1Price: 99 Euro
2. Audio Amplifiers
1x40W power amplifier “made in Germany”
This digital audio amplifier has the smallest dimensions, nearly no weight and highest efficiency, resulting in very little self heating.
Highly suitable for leight weight foam aircrafts. It can be powered from 3-6S LiPos.
It can be operated with any speaker technology (traditional cone speaker or “Exciter”).
The speaker impedance should be adapted to the supply voltage.
1x40W amplifier manual (PDF) Price: 59 Euro
2x60W digital power amplifier, Version 2
Ideal amplifier for 12-24V powered large scale vehicles like tanks.
Small dimensions, low heating and VERY powerfull !
This amp. comes together with the “Audo-Isoloator” preventing any grounding problems.
-> see detailed descriptioin below.
Hint:
This amp. can be combined also with the TBS5 sound unit. In this case the Audio-Isolator is not necessary. Picture
(Illustration similar)
Datasheet Price: 79 Euro
1x30W digital power amplifier
This imported amplifier has similar propberties than the 1x40W amplifier. The lower output power of 1x30W is enough to drive one or two R10S speakers at their capabilities. It can be connected directly to the TBS Mini V2 without any external cirquitry.
It will be delivered 100% tested, cables are included.
(Illustration similar)
Hint:
This amplifier can’t be connected directly to the TBS Mini V1. This requires an external volume controller.
-> See TBS Mini V1 manual page 10
1x30W amplifier datsheet Price: 29 Euro
2x10W digital audio amplifier
Ultra compact 2x10W digital amplifier for vehicles.
High efficiency and nearly no heating results in astonishing volume.
Ideal in combination with the TBS Mini V2 soundunit.
Supply voltage: 7,4 - 15V (2-4S LiPo or 12V Battery. NOT suitable for 7,2V NC battery packs!
Dimension: about 40 x 30 x 7 mm
Weight: about 15g
2x10W Manual (PDF) Price: 29€
Audio Isolator
This device ensures a electrical / galvanic isolation between the receiver and main battery. It is simply plugged between the soundunit and the external amplifier and separates the two power sources properly.
It is highly recommended if already a ESC with optoisolator input for the speed signal is used.
It prevents any “ground loops” or noise feed into the receiver supply by the ESC for example. This may happen through devices beeing connected to the receiver AND to the main battery (f.e. by sound units having a internal power amplifier or ESCs without a “opto input”).
Such devices connect minus of the receiver to minus of the main battery!
The “ground mess” gets even worse, if multiple external amplifiers are connected to a sound system directly.
If a soundunit is powered by a separate battery, NO Audio-Isolator is necessary.
In addition, the device allows powering an amplifier by a main battery having more than 6S (see manual).
Attention:
The audio isolator MUST be plugged at the SPEAKER connector of the TBS Mini V2! NOT the amplifier connector.
Audio-Isolator manual Price: 18 Euro
3. Speaker
A: Traditional cone speakers:
Standard speaker for airplanes: Visaton R10S.
Good power/weight ratio at highest efficiency and low price
Power: 30W music
Impedance: 4 and 8 Ohm available
Dimension: 100 x 100 x 36mm
Weight: 160g .
Sound pres.: 90dB (1W/1M)
Pice: 12 Euro
Speaker for limited space Monacor SPX-21M
Best power/weight radio, very small at good efficiency
Power: 25W music
Impedance: 4 Ohm
Dimension: 50 x 50 x 34mm
Weight: 90g
Sound pres.: 84dB (1W/1M)
Pice: No longer on stock! Please order externally
Small and very light weight speaker Typ BE-2
Recommended for smaller planes or installation in turbine dummys
Power: about 15W music, 10W Pink nominal
Impedance: 4 Ohm
Dimension: 54x26mm
Weight: 51g .
Sound pres.: 80dB (1W/1M)
Price: 18 Euro
Datasheet
Different Visaton brand speakers are on stock.
We will recommend the most suitable one for your application.
For aircraft applications the following speakers are recommended, in combination with the 1x40W amplifier:
2 pcs R10S (Ideal setup for airplanes) or 2 pcs SPX-21M (at limited space in the model)
A very good alternative for foam models is using an Exciter (-> see below)
Tbs Dtv Sound Cards & Media Devices Driver Download 64-bit
B: Exciter or Transducer “speaker”:
This kind of “speaker” is reduced to the drive/motor of a conventional speaker. It is installed on any surface which acts as the membrane, producing the sound. How it will sound, depends on many factors.
F.e. mechanical siffness of the material, its shape and density.
Please note that the whole structure (f.e. hull of of plane) can vibrate heavily, according to the set volume!
All installed items are exposed to it.
Up to now NO vibration damages are reported.
Exciters were already used also in wood and GFK models sucessfully.
We tried to find out which speaker technology is the best. For this, we did a test series, using different exciters and conventional speakers on different objects.
The result can be found here.
This is the recommended installation guide for a exciter.
Two examples of exciters
Manufacturer documents, explaining this speaker principal can be found here:
http://www.visaton.de/downloads/pdf/visaton_exciter_principles.pdf
http://www.daytonaudio.com/media/resources/understanding-and-using-dayton-audio-exciters-revised.pdf
US and world wide supplier f.e.:
http://www.parts-express.com/dayton-audio-daex25vt-4-vented-25mm-exciter-20w-4-ohm--295-222
Recommended exciter:
DAEX25FHE-4 (24W/4Ohm, Ф58 x 21mm, 110g)
No longer on stock, please source on your own.
4. FAQ’s
This section will be extended continuously
- Why are the Benedini amplifiers so expensive?
Our amlifiers are import taxed, are delivered with plugs and cables, are 100% tested and include 19% VAT.
Sourcing 3rd party amplifiers on your own is no problem but there will be NO support at all !
External connections are on your own risk. Possible typical damages can be traced and are out of any warranty.
Just to make this very clear in advance !
- Why is the TBS Mini V2 more expensive?
The price for the old TBS Mini V1 was never increased for 10 years! I covered all price changes. Beside that production cost of the new Mini is higher.
- Is the 1x40W amplifier compatible to the new TBS Mini V2?
NOT directly but after some changes -> Instruction follows
5. Discontinued products
Soundunit TBS 5
-> Service and repair still avialable
RC soundunit for simultaneous playing of engine and special sounds. A tone control stage is integrated, to adjust bass and trebble to your personal taste. All inputs are galvanic isolated and connected by plugs. The soundunit can be controlled by a proportional channel or switched signals. Two soundsynchron working outputs are provided for switching functionality. They can be used for muzzle flashing simulation by LEDs.
Features:
- 22050 Hz samplerate for highest sound quality
- Integrated tone control stage for bass and treble
- Up to two drive motors can be scanned, ideal for tracked vehicles
- Continious speed sound variation, infinitely and direct responding to speed changes
- Controlled by prop.channel OR digital inputs (Multiswitch)
- All wires included
- Optional smoke generator, for authentic exhaust simulation
- Galvanic Isolation of all input signals
- External amplifier, no limitation in output performance
- Large sound collection of military and civil vehicles available
Manual TBS5 (PDF)
Soundunit TBS Micro V2.0
*** Smalles soundunit available ***
Dimensions only:
11,5 x 24,5 (16,5) mm = 0,45 x 1,0 (0,64) inch
Due to its size this RC sound unit is ideal for 1/87 scale models. All electrical connections can be done by plugs or directely with wires soldered at the corners of the PCB.
In this case the PCB can be cut down to 11,5x16,5mm ( 0,45 x 0,64 inch).
In comparison to the TBS Mini (see above) the sound memory capacity is 23s . This is plenty enough for car or truck sounds.
Manual TBS Micro
Tbs Dtv Sound Cards & Media Devices Driver Download Windows 7
Prices TBS Micro:
Fully prorgramed (ready to run) without sockets and cables: 69 Euro
Fully programed (ready to run) including socket and cables: 85 Euro
USB Programingadaptor for TBS Micro + Mini (two plugs): 22 Euro
(This adaptor is needed only once in case you want to do custom configurations)
4x40W analog power amplifier (at 14V, 2Ohm speaker, 10% THD) Drivers wacom mice & touchpads.
This high power amplifier can be combined with all Benedini Soundunits. It has a internal “max volume” indication.
This means the volume can be increased until the LED starts flashing. Of course this requires speakers with a according power rating. The combination with our R10S or SPH-30 speakers is ideal.
The amplifier can be operated with 1-4 speakers:
Speakers Nr.1+2 are connected by the main plug, speakers Nr.3+4 by solder pads at the bottom of the PCB.
Using a 4S LiPo power supply is ideal. 3S supply is possible. The capacity depends of the number of speakers. For 30min flight and two R10S speakers, about 1500 mAh are recommended.
This high power amplifier needs sufficient cooling. It MUST be mounted in a well ventilated area of the plane (airstream) !
Power supply range: 9-18V
4x40W amplifier manual (PDF)
2x6W digital audio amplifier
Ultra compact 2x6W digital amplifier for vehicles, including volume control on the rear side.
High efficiency and nearly no heating results in astonishing volume.
Ideal in combination with the TBS Mini soundunit.
Supply voltage: 7,4 - 14V (2-3S LiPo or 12V Battery. NOT suitable for 7,2V NC battery packs!
Dimension: ca. 30 x 37 x 7 mm (incl. power plug)
Weight: ca. 12g
Tbs Dtv Sound Cards & Media Devices Driver Downloads
2x6W Manual (PDF) Price: 29€
